Place of Origin: Henan, China
Application: Cranes,monorails,electric hoists,Mobile automation equipment
Material: 99.9% Oxygen-free copper Copper,PVC[Housing]
Color: Orange(Dangerous Color)
Temperature resistance: VO Level Fire Rating -40°C -75°C
Protection Class: IP20 Waterproof and dust level
Pole: 3/4/6 Pole
Certificate: ISO9001 CCC CE
Rated Voltage: 380/660V
Rated Current: 30A-140A
No seam slip line safe, stable, no interface (except power supply point) small size, space, easy installation, affordable, to adapt to a variety of corners with electric hoist.Product Application
| Product Type Marking Instructions | MKD | X | Y | NA |
| Product model | Pole | Copper square | Rated current |
| 3P-Continuous Insulated Conductor Rails | ||||
| Code | Type | Specification | Length | Weight(kg) |
| ZG-301 | ZG-3-6-30A | 6mm 2 -30A | 1M | 0.45 |
| ZG-302 | ZG-3-10-50A | 10mm 2 - 50A | 1M | 0.58 |
| ZG-303 | ZG-3-16-80A | 16mm 2 - 80A | 1M | 0.75 |
| ZG-304 | ZG-3-20-100A | 20mm 2 -120A | 1M | 0.90 |
| ZG-305 | ZG-3-25-125A | 25mm 2 - 125A | 1M | 1.00 |
| ZG-306 | ZG-3-35-140A | 35mm 2 - 140A | 1M | 1.25 |
| Main Features | |
| 1 | Safe and reliable, protection class to IP20, waterproof, dustproof, to prevent finger electric shock. |
| 2 | Energy saving, the use of international general conductive materials, can minimize the power supply line in the power loss. |
| 3 | Maximum moving speed of 200 m / min. |
| 4 | Easy to install and often maintenance. |
| 5 | Long life, the unique form of the conductor sheath, a great increase in the life of the slide wire system. |
| 6 | Can be made according to the work of equipment bending slip cable system. |
| 7 | Insulation sheathed with anti-UV ingredients for outdoor use. |
| 8 | Provide standard PVC insulation sheath and PPO and other heat-resistant insulation sheath, suitable for different working environment. |
| 9 | Full range of products can achieve VO level fire rating, -40 ° C environmental requirements. |
FAQ
| What is the material? | Using 99.99% of oxygen-free copper, PVC shell material |
| Is there a connector? | insulated conductor rails, no connector, current stable |
| Is there a gift? | Each 1.2 m slide standard comes standard with 1PCS rail clamp and 1PCS iron plate |
| Minimum order quantity? | 1 Meter or according to customer demand |
| Delivery | 15 working days after receipt of payment. |
